Design & manufacture: API 6D, API 608, ANSI B16.34, BS5351
Face to face: ANSI B16.10
Inspection and test: API 598
Flanged ends: ANSI B16.5
BW ends: ANSI B16.25
Fire safe: API 607, API 6FA
Anti-static
Connection dimensions of worm gear actuator, electric actuator, pneumatic actuator to ISO 5211standard
|
Body & Bonnet |
Cast Steel ASTM A216 WCB, A352 LCB, Stainless Steel ASTM A351 CF8, CF8M, CF3, CF3M |
|
Ball |
A105, F304, CF8(M), CF3(M) |
|
Stem |
F6, F304(L), F316(L) |
|
Seat |
F6, F304(L), F316(L) |
|
Seat ring |
PTFE, POM |
|
DN |
L mm |
H mm |
D0 mm |
Weight kg |
|
150 lbs |
|
15 |
108 |
59 |
130 |
2.3 |
|
20 |
117 |
63 |
130 |
3.0 |
|
25 |
127 |
75 |
160 |
4.5 |
|
40 |
165 |
95 |
230 |
7.0 |
|
50 |
178 |
153 |
400 |
15.0 |
|
65 |
191 |
165 |
400 |
20.0 |
|
80 |
203 |
195 |
600 |
25.0 |
|
100 |
229 |
213 |
850 |
40.0 |
|
150 |
394 |
272 |
1100 |
97.0 |
|
200 |
457 |
342 |
1500 |
160.0 |
|
250 |
533 |
495 |
350 |
240.0 |
