Design & manufacture: MSS SP-67, BS 5155, API 609
Wafer Type compatible with ANSI, DIN, BS, JIS flanges
Applicable Temperature: -40¡æ to 130¡æ
Lever operated for size 1¡± to 12¡±; Manual gear operated for size 1¡± to 24¡±; Electric/pneumatic actuator for size 1¡± to 24¡±
|
Body |
Cast Iron, Ductile Iron, Stainless Steel, Carbon Steel |
|
Disc |
Ductile Iron, Stainless Steel, Al-bronze |
|
Shaft |
Zinc plated Steel, Stainless Steel |
|
Seat |
NBR, EPDM, PTFE, Viton, Neoprene |
|
Size |
A mm |
B mm |
C mm |
D mm |
E mm |
|
PN10 |
|
25 |
61 |
110 |
32 |
12.7 |
85 |
|
32 |
61 |
110 |
32 |
12.7 |
100 |
|
40 |
79 |
145 |
32 |
12.7 |
110 |
|
50 |
85 |
162 |
32 |
12.7 |
125 |
|
65 |
98 |
174 |
32 |
12.7 |
145 |
|
80 |
104 |
181 |
32 |
12.7 |
160 |
|
100 |
123 |
200 |
32 |
15.9 |
180 |
|
125 |
136 |
216 |
32 |
19.1 |
210 |
|
150 |
148 |
225 |
32 |
19.1 |
240 |
|
200 |
186 |
260 |
38 |
22.2 |
295 |
|
250 |
212 |
292 |
38 |
28.6 |
350 |
|
300 |
251 |
337 |
38 |
31.8 |
400 |
|
350 |
277 |
388 |
45 |
31.8 |
460 |
|
400 |
308 |
400 |
51 |
33.3 |
515 |
|
450 |
342 |
422 |
51 |
38.1 |
565 |
|
500 |
374 |
479 |
64 |
41.3 |
620 |
|
600 |
459 |
582 |
70 |
50.8 |
725 |
