Design & manufacture: MSS SP-67, BS 5155, API 609
Wafer Type compatible with ANSI, DIN, BS, JIS flanges
Applicable Temperature: -40¡æ to 200¡æ
Lever Operated for size from 1 1/2¡± to 12¡±; Manual gear operated for size from 1 1/2¡± to 48¡±; Electric/pneumatic actuators for size from 1 1/2¡± to 48¡±
|
Body |
Cast Iron, Ductile Iron, Stainless Steel, Carbon Steel |
|
Disc |
Ductile Iron, Stainless Steel, Al-bronze |
|
Shaft |
Zinc plated Steel, Stainless Steel |
|
Seat |
NBR, EPDM, PTFE, Viton, Neoprene |
|
Size |
A mm |
B mm |
C mm |
D mm |
E mm |
|
PN10 |
|
40 |
70 |
145 |
32 |
12.7 |
110 |
|
50 |
76 |
162 |
32 |
12.7 |
125 |
|
65 |
89 |
174 |
32 |
12.7 |
145 |
|
80 |
95 |
181 |
32 |
12.7 |
160 |
|
100 |
114 |
200 |
32 |
15.9 |
180 |
|
125 |
127 |
213 |
32 |
19.1 |
210 |
|
150 |
139 |
225 |
32 |
19.1 |
240 |
|
200 |
177 |
260 |
38 |
22.2 |
295 |
|
250 |
203 |
292 |
38 |
28.6 |
350 |
|
300 |
242 |
337 |
38 |
31.8 |
400 |
|
350 |
277 |
368 |
45 |
31.8 |
460 |
|
400 |
308 |
400 |
51 |
33.3 |
515 |
|
450 |
342 |
422 |
51 |
38.1 |
565 |
|
500 |
374 |
479 |
64 |
41.3 |
620 |
|
600 |
459 |
562 |
70 |
50.8 |
725 |
|
700 |
520 |
624 |
72 |
55 |
840 |
|
750 |
545 |
650 |
72 |
55 |
900 |
|
800 |
575 |
672 |
72 |
55 |
950 |
|
900 |
635 |
768 |
77 |
75 |
1050 |
|
1000 |
685 |
823 |
85 |
85 |
1160 |
|
1200 |
839 |
940 |
150 |
92 |
1380 |
